INT-170S
SBC-170S
Intel® 6th Generation Core i7/ i5/ i3
6.7” Fanless Heat-Sink Mainboard
Product Drawings / Product Detail
6th Generation
Intel 6th Generation Core i7/ i5/ i3 processor
Industrial SBC(Single Board Computer), Fanless
Specification
System
| CPU | Intel® 6th Generation Core i7 / i5 / i3 Processor |
| BIOS | AMI uEFI BIOS, 128Mbit SPI Flash ROM |
| System Chipset | Intel Q170 Express Chipset |
| I/O Chipset | NCT6106D(Nuvoton) |
| System Memory | Two 260-pin DDR4 2133MHz SO-DIMM Socket, Supports Up to 32GB Max |
| RAID | RAID 0,1 |
| H/W Status Monitor | CPU temperature monitoring, Voltage monitoring CPU fan speed control |
| Expansion Interface | 1x PCIe(16x), 1x Full size Mini-PCIe, 1x mSATA |
Display
| Chipset | Intel® Intergrated HD Graphics 530 |
| Resolution | VGA Mode: 1920 x 1200 @ 60Hz HDMI Mode: 4096 x 2160 @ 30Hz (Supports HDMI 1.4a) DP Mode : 4096 x 2304 @60Hz |
| Multiple Display | Triple Display |
Audio
| Chipset | Realtek ALC888S Support 5.1-CH Audio |
| Audio Interface | Mic-in, Line-out(SPK-OUT) |
Ethernet
| Chipset | 1x Intel® I219LM PCIe Gigabit Ethernet 1x Intel® 82574L PCIe Gigabit Ethernet (support EtherCAT) |
| Ethernet Interface | 10/100/1000 Base-Tx Gigabit Ethernet Compatible |
I/O
| LAN | 2 Port / 2 x Gigabit Ethernet | On-Board | |
| HDMI | 1 Port / 1 x HDMI | On-Board | |
| VGA | 1 Port / 1 x VGA | On-Board | |
| USB |
4 Port / 4 x USB 3.0, 5 Port / 5 x USB 2.0 |
On-Board Cable |
4 x USB3.0 5 x USB2.0 |
| DC-IN | 1 Port | On-Board | |
| LVDS | 1 Port / 1 x LVDS | Cable | |
| RS-232 | 4x RS232 | Cable | |
| RS-422 | 1x RS422 | Cable | |
| RS-485 | 1x RS485 | Cable | |
| SATA | 3 Port / 3 x SATA II | Cable | |
| mSATA | 1 Port (colay with full size Mini-PCIe) | ||
| PCIe | 1 Port / PCIe(16x) | Card | |
| Mini PCIe | 1 Port / 1 Full-size Mini PCIe | Card |
Mechanical and Environment
| Power Type | 12V~24V DC-in (DC Jack / 4-pin ATXPWR Con) |
| Operating Temperature | 0 ~ 60°C (32 ~ 140°F) |
| Storage Temperature | -40 ~ 75°C (-40 ~ 167°F) |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Dimensions | 6.7" x 6.7" (170mm x 170mm) |
| Weight | 1130g |
